*SOLD*
Built like a piece of a Audio Jewelry . Sounds sublime !
| Model 2002A | Solid State Stereo Integrated Amplifier | ||||
| <Power amplifier section> | |||||
| Effective output (1kHz) |
|
||||
| Music Power (IHF) | 46W (4Ω) 38W (8Ω) |
||||
| Total harmonic distortion (8Ω) | 0.8% (rated output) 0.2% (rated output-3dB) |
||||
| Intermodulation distortion | 0.8% (rated output) 0.2% (rated output-3dB) |
||||
| Output bandwidth | 20Hz-30kHz | ||||
| Frequency characteristic | 20Hz-30kHz ± 2dB | ||||
| Output terminal | Speakers: 4Ω to 16Ω Headphones: 4Ω to 16Ω |
||||
| Damping factor | 50 (1kHz, 8Ω) | ||||
| <Preamplifier section> | |||||
| Input sensitivity / impedance | Phono1, 2: 2mV / 50kΩ Tuner, AUX, Tape PlayA, B: 150mV / 50kΩ |
||||
| SN ratio | Phono1, 2:60dB Tuner, AUX, Tape PlayA, B: 70dB |
||||
| Output level / impedance |
|
||||
| Tone control | Bass: ± 10dB (100Hz) Treble: ± 10dB (10kHz) |
||||
| Loudness control (rated output -30dB) |
100Hz: + 8dB 10kHz: + 4dB |
||||
| <Comprehensive> | |||||
| Power-supply voltage | AC240 V 50Hz | ||||
| Power consumption (Electrical Appliance and Material Control Law) | 40W | ||||
| External dimensions | Width 352 x Height 118 x Depth 240 mm | ||||
| weight | 5.4kg | ||||
Product Description
